TPD2E1B06DRLR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPD2E1B06DRLR
Manufacturer

TI
ChipWorker Part#

CW23716637
Category

TVS Diode
Package

SOT-553-6
Description

ESD Suppressor Diode Array 15kV 6Pin SOT T/R
Documentation

Datasheet

TPD2E1B06DRLR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPD2E1B06DRLR Specifications

Attribute	Attribute Value

Part Number	TPD2E1B06DRLR
Manufacturer	TI
ChipWorker Part#	CW23716637
Category	TVS Diode
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-553-6
Capacitance	1.3 pF
Breakdown Voltage	7 V
Number of Channels	2 Channel
Clamping Voltage	15 V
Peak Pulse Power	35 W
Min Breakdown Voltage	7 V
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
	expand all
Size-Height	0.55 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The TPD2E1B06 device is a dual-channel, ultra-low capacitance ESD protection device. It offers ±10-KV IEC contact ESD protection. Its 1-pF line capacitance makes it suitable for a wide range of applications. Typical application interfaces are USB 2.0, LVDS, and I2C. The TPD2E1B06 device has two common layout methods, and both are highlighted in _Layout_.
