TPS71501MDCKREP ,Voltage Regulator - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

131 points

Part No

TPS71501MDCKREP
Manufacturer

TI
ChipWorker Part#

CW17457193
Category

Voltage Regulator
Package

SC-70-5
Description

TEXAS INSTRUMENTS TPS71501MDCKREP LDO Voltage Regulator, Adjustable, 3V to 24V in, 415mV drop, 1.2V to 15V/50mA out, SC-70-5
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.47

Buy TPS71501MDCKREP

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TPS71501MDCKREP Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TPS71501MDCKREP Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TPS71501MDCKREP
Manufacturer	TI
ChipWorker Part#	CW17457193
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SC-70-5
Number of Outputs	1 Output
Output Voltage	1.2V ~ 15V
Output Current	50 mA
Number of Positions	5 Position
Power Dissipation	0.32 W
Quiescent Current	3.00 µA
Output Capacitor Type	Ceramic
voltage rating	415 mV
Number of Regulated Outputs	1 Output
Input Voltage (Max)	24 V
Input Voltage (Min)	3 V
Output Voltage (Max)	15 V
Output Voltage (Min)	1.2 V
Output Current (Max)	0.05 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	320 mW
Accuracy	±6.25 %
Input Voltage	2.5V ~ 24V
	expand all
Size-Height	1 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The TPS71501 low-dropout (LDO) voltage regulators offer the benefits of high input voltage, low dropout voltage, low-power operation, and miniaturized packaging. The device, which operates over an input range of 2.5 V to 24 V, is stable with any capacitor (≥0.47 µF). The low dropout voltage and low quiescent current allow operation at extremely low power levels. Therefore, the devices are ideal for powering battery-management ICs. Specifically, because the devices are enabled as soon as the applied voltage reaches the minimum input voltage, the output is quickly available to power continuously operating battery-charging ICs.
The usual PNP pass transistor has been replaced by a PMOS pass element. Because the PMOS pass element behaves as a low-value resistor, the low dropout voltage, typically 415 mV at 50 mA of load current, is directly proportional to the load current. The low quiescent current (3.2 µA typically) is stable over the entire range of output load current (0 mA to 50 mA).
