UPS1E101MED ,Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum - Nichicon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

126 points

Part No

UPS1E101MED
Manufacturer

Nichicon
ChipWorker Part#

CW11770550
Category

Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum
Package

Radial, CAN
Description

100uF ±20% 25V 250mA(100kHz)250mA Φ6.3mm
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.29

Buy UPS1E101MED

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

UPS1E101MED Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

UPS1E101MED Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	UPS1E101MED
Manufacturer	Nichicon
ChipWorker Part#	CW11770550
Category	Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	Radial, CAN
Pin Pitch	2.5 mm
Voltage Rating (DC)	25 V
Operating Voltage	25 VDC
Capacitance	100 µF
Equivalent Series Resistance (ESR)	0.5 Ω
Capacitance Tolerance	±20 %
Part Family	UPS
Ripple Current	250 mA
Ripple Current (Low Frequency)	125mA @120Hz
Ripple Current (High Frequency)	250mA @100kHz
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-55 ℃
Voltage Rating	25 V
	expand all
Size-Length	11 mm
Size-Height	11 mm
Size-Diameter	6.30 mm
Operating Temperature	-55℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Bulk
Minimum Packing Quantity	4000
Life (Hours)	2000 h
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

**Features:
**
* Wide Temperature Range Type, Miniature Sized
* Compliant to the RoHS directive (2002/95/EC)**
Specifications:
**
* Temperature Range: –55°C to +105°C**
**
* Rated Voltage Range: 6.3-450 V**
**
* Rated Capacitance Range: 0.47 to 15000 μF**
**
* Capacitance Tolerance: ±20% at 120 Hz, 20°C
