V23105A5307A201 - TE Connectivity
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoV23105A5307A201
-
ManufacturerTE Connectivity
-
ChipWorker Part#CW37828942
-
CategoryIndustrial Relay
-
PackageDIP
-
DescriptionSignal Relay 48VDC 3A DPDT (( 20.2mm 10mm 11mm)) Through Hole
-
DocumentationDatasheet
