ZB5AS844 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ZB5AS844
Manufacturer

Schneider Electric
ChipWorker Part#

CW9998204
Category

Switch Accessory
Description

Switch: emergency stop; 2Position; 22mm; red; Illumin: none; IP66
Documentation

Datasheet

ZB5AS844 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ZB5AS844 Specifications

Attribute	Attribute Value

Part Number	ZB5AS844
Manufacturer	Schneider Electric
ChipWorker Part#	CW9998204
Category	Switch Accessory
Documentation	Datasheet
Actuator Type	Button
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-25 ℃
	expand all
Color	Red
Material	Plastic
Operating Temperature	25℃ ~ 70℃
Housing Material	Plastic
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2018/01/15

Product Description

The ZB5AS844 is an Ø 40mm emergency stop pushbutton head for use with Harmony XB5 switches.
Red mushroom head unmarked
22mm mounting diameter
Turn to release
Trigger action and mechanical latching operator
Plastic bezel
Operating temperature range -25°C to +70°C
IP66 rated and conformance to IEC 60529 standard
NEMA 4X, NEMA 13 rated
