1SMA24CAT3G Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | 1SMA24CAT3G | |
| Manufacturer | ON Semiconductor | |
| ChipWorker Part# | CW84471317 | |
| Category | TVS Diode | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 2 Pin | |
| Case/Package | SMA | |
| Halogen Free Status | Halogen Free | |
| Breakdown Voltage | 26.7 V | |
| Number of Circuits | 1 Circuit | |
| Clamping Voltage | 38.9 V | |
| Max Repetitive Reverse Voltage (Vrrm) | 24V | |
| Test Current | 1 mA | |
| Max Breakdown Voltage | 29.5 V | |
| Peak Pulse Power | 400 W | |
| Min Breakdown Voltage | 26.7 V | |
| Reverse Breakdown Voltage | 26.7 V | |
| Operating Temperature (Max) | 150 ℃ | |
| Operating Temperature (Min) | -65 ℃ | |
| Junction Temperature | -65℃ ~ 150℃ | |
| expand all | ||
| Size-Length | 4.57 mm | |
| Size-Width | 2.92 mm | |
| Size-Height | 2.2 mm | |
| Operating Temperature | -65℃ ~ 150℃ (TJ) | |
| Product Lifecycle Status | Active | |
| Packaging | Tape & Reel (TR) | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance Edition | 2015/12/17 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- 400 Watt Peak Power Zener Transient Voltage Suppressors
- Bidirectional
- The SMA series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. The SMA series is supplied in ON Semiconductor’s exclusive, cost-effective, highly reliable Surmetic™ package and is ideally suited for use in communication systems, automotive, numerical controls, process controls, medical equipment, business machines, power supplies and many other industrial/consumer applications.
- Features
- • Working Peak Reverse Voltage Range − 10 V to 78 V
- • Standard Zener Breakdown Voltage Range − 11.7 V to 91.3 V
- • Peak Power − 400 Watts @ 1 ms
- • ESD Rating of Class 3 (> 16 kV) per Human Body Model
- • Response Time is Typically < 1 ns
- • Flat Handling Surface for Accurate Placement
- • Package Design for Top Slide or Bottom Circuit Board Mounting
- • Low Profile Package
- • Pb−Free Packages are Available
