553MILFT - Integrated Device Technology

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

553MILFT
Manufacturer

Integrated Device Technology
ChipWorker Part#

CW27551996
Category

Clock Buffer, Driver, PLL IC
Package

SOIC-8
Description

Clock Fanout Buffer 4Out 8Pin SOIC Clock Fanout Buffer 4Out 8Pin SOIC
Documentation

Datasheet

553MILFT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

553MILFT Specifications

Attribute	Attribute Value

Part Number	553MILFT
Manufacturer	Integrated Device Technology
ChipWorker Part#	CW27551996
Category	Clock Buffer, Driver, PLL IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Frequency	200 MHz
Number of Outputs	4 Output
Number of Circuits	1 Circuit
Number of Positions	8 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	40 ℃
Supply Voltage	2.375V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	2.375 V
	expand all
Size-Length	4.9 mm
Size-Width	3.9 mm
Size-Height	1.5 mm
Size-Thickness	1.50 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Description
The ICS553 is a low skew, single input to four output, clock buffer. Part of ICS’ ClockBlocks™ family, this is our lowest skew, small clock buffer. See the ICS552-02 for a 1 to 8 low skew buffer. For more than 8 outputs see the MK74CBxxx Buffalo™ series of clock drivers.
ICS makes many non-PLL and PLL based low skew output devices as well as Zero Delay Buffers to
synchronize clocks. Contact us for all of your clocking needs.
Features
• Extremely low skew outputs (50 ps maximum)
• Packaged in 8-pin SOIC
• Available in Pb (lead) free package
• Low power CMOS technology
• Operating Voltages of 2.5 to 5V
• Output Enable pin tri-states outputs
• 5V tolerant input clock
**• **Commercial (0 to +70°C) and Industrial (-40 to +85°C) temperature ranges available
