56200C - muRata

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

56200C
Manufacturer

muRata
ChipWorker Part#

CW48533600
Category

Transformer
Package

SIP
Description

Current Transformer 1:200 500VDC 1.87Ω/2.81Ω Prim. DCR 80000uH/150000uH Prim. 10000mA Prim. 3Term. PC Pin Thru-Hole
Documentation

Datasheet

56200C Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

56200C Specifications

Attribute	Attribute Value

Part Number	56200C
Manufacturer	muRata
ChipWorker Part#	CW48533600
Category	Transformer
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	SIP
Inductance	80 mH
Input Current	10 A
Isolation Voltage	500 VDC
DC Resistance (DCR)	2.81 Ω
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	expand all
Size-Length	16.79 mm
Size-Width	8.89 mm
Size-Height	20.19 mm
Weight	5.70 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

56200C is manufactured by Murata Power and is categorized in the Current Sense Transformers category. 56200C is described as CURR SENSE XFMR 10A T/H. Perfect Parts is a supplier of Transformers and other Miscellaneous.
