The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

7201MD9ABE
Manufacturer

C&K Components
ChipWorker Part#

CW3387387
Category

Toggle Switch, Switch Toggle
Package

120
Description

Switch Toggle ON None ON DPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket
Documentation

Datasheet

7201MD9ABE Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

7201MD9ABE Specifications

Attribute	Attribute Value

Part Number	7201MD9ABE
Manufacturer	C&K Components
ChipWorker Part#	CW3387387
Category	Toggle Switch, Switch Toggle
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	120
Contact Plating	Gold
Voltage Rating (DC)	20 V
Voltage Rating (AC)	20 V
Current Rating	5 A
Insulation Resistance	1 GΩ
Number of Rows	2 Row
Contacts Type	2PDT
Number of Positions	3 Position
Contact Resistance	≤10 MΩ
Contact Current Rating	5.00 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-30 ℃
Voltage Rating	20 V
Voltage Rating (DC Max)	20 V
Voltage Rating (AC Max)	20 V
Maximum Contact Resistance (Max)	<10 mΩ
	expand all
Size-Length	12.7 mm
Size-Height	11.43 mm
Contact Material	Gold
Operating Temperature	-30℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
HTS Code	8536509065
ECCN Code	EAR99

Product Description

The 7000 series Miniature Rocker and Lever Handle Switch with epoxy terminal-seal compatible with bottom wash cleaning. It has black nylon concave (standard V) actuator, rectangular panel cut-out and stainless steel housing.
