ADUM5000ARWZ ,Interface Isolator, Digital Isolator - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

243 points

Part No

ADUM5000ARWZ
Manufacturer

ADI
ChipWorker Part#

CW373287
Category

Interface Isolator, Digital Isolator
Package

SOIC-16
Description

ANALOG DEVICES ADUM5000ARWZ Digital Isolator, 1Channel, 2.7V, 5.5V, WSOIC, 16Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 2.83

Buy ADUM5000ARWZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADUM5000ARWZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADUM5000ARWZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADUM5000ARWZ
Manufacturer	ADI
ChipWorker Part#	CW373287
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	2.70V (min)
Operating Voltage	2.7V ~ 5.5V
Power Rating	330 mW
Number of Outputs	1 Output
Output Voltage	5 V
Output Current	100 mA
Supply Current	4.00 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Output Power	500 mW
Isolation Voltage	2.5 kV
Switching Frequency	180 MHz
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Voltage (Max)	5.5 V
Output Voltage (Min)	3.3 V
Output Current (Max)	100 mA
Input Power (Max)	0.5 W
Input Power (Max)	500 mW
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
Input Voltage	3V ~ 5.5V
	expand all
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ADUM5000ARWZ is an Isolated DC-to-DC Converter based on the Analogue Devices, Inc., iCoupler® technology. In this device provides regulated, isolated power in several combinations of input and output voltages. The Analogue Devices chip scale transformer, iCoupler technology, transfers isolated power in this DC-to-DC Converter with up to 33% efficiency. The result is a small form factor, total isolation solution. isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissions standards.
Regulated 3.3 or 5V output
Up to 500mW output power
Thermal overload protection
Product features patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD.
