A000073 ,Microprocessor Primary Platform - Arduino

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

122 points

Part No

A000073
Manufacturer

Arduino
ChipWorker Part#

CW3256676
Category

Microprocessor Primary Platform
Package

SMD
Description

ATmega328 Microcontroller Uno SMD Development Board 16MHz CPU 2KB RAM 1KB/32KB EEPROM/Flash
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 21.41

Buy A000073

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

A000073 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

A000073 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	A000073
Manufacturer	Arduino
ChipWorker Part#	CW3256676
Category	Microprocessor Primary Platform
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	SMD
RAM Memory Size	2 KB
Number of Bits	8 Bit
Core Architecture	AVR
	expand all
Size-Length	3 in
Size-Width	2.5 in
Size-Height	0.05 in
Weight	0.009071848 kg
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Similar & Replacement Parts

Similar products

Product Description

The A000073 is a Arduino Uno SMD R3 development board based on the ATmega328 microcontroller. The ATmega328 is a low power CMOS 8bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega328 achieves throughputs approaching 1MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. The Arduino Uno SMD R3 evaluation board has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16MHz crystal oscillator, a USB connection, a power jack, an ICSP header and a reset button. It contains everything needed to support the microcontroller, simply connect it to a computer with a USB cable or power it with a AC to DC adapter or battery to get started. The Uno differs from all preceding boards in that it does not use the FTDI USB to serial driver chip.
ATmega16U2 instead 8U2 as USB to serial converter
Stronger RESET circuit
1.0 pinout
Input voltage (recommended) range from 7V to 12V
5V operating voltage
32KB flash memory
0.5KB flash memory for bootloader
50mA of DC current for 3.3V pin
1KB EEPROM
2KB SRAM

expand all
