ACPL-C87B-000E ,Isolation Amplifier IC - Broadcom

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

120 points

Part No

ACPL-C87B-000E
Manufacturer

Broadcom
ChipWorker Part#

CW5551496
Category

Isolation Amplifier IC
Package

SOIC-8
Description

BROADCOM LIMITED ACPL-C87B-000E Isolation Amplifier, Optically, 1 Amplifier, 9.9mV, 5kV, 3V to 5.5V, SOIC, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

150 pcs In Stock
Estimated Price

$ 6.19

Buy ACPL-C87B-000E

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ACPL-C87B-000E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ACPL-C87B-000E Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ACPL-C87B-000E
Manufacturer	Broadcom
ChipWorker Part#	CW5551496
Category	Isolation Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	10.5 mA
Number of Circuits	1 Circuit
Number of Positions	8 Position
Bandwidth	100 kHz
Isolation Voltage	5 kV
Input Offset Voltage	9.9 mV
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	100 kHz
Supply Voltage	3V ~ 5.5V
	expand all
Size-Length	5.85 mm
Size-Width	6.807 mm
Size-Height	3.18 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The ACPL-C87B/C87A/C870 voltage sensors are*optical isolation amplifiers** designed specifically for voltage sensing. Its 2V input range and high 1GΩ input impedance, makes it well suited for isolated voltage sensing requirements in electronic power converters applications including motor drives and renewable energy systems. In a typical voltage sensing implementation, a resistive voltage divider is used to scale the DC-link voltage to suit the input range of the voltage sensor. A differential output voltage that is proportional to the input voltage is created on the other side of the optical isolation barrier.
For general applications, the ACPL-C87A (±1% gain tolerance) and the ACPL-C870 (±3% gain tolerance) are recommended. For high precision requirements, the ACPL-C87B (±0.5% gain tolerance) can be used. The ACPL-C87B/C87A/C870 *optical isolation amplifiers** family operates from a single 5V supply and provides excellent linearity. An active-high shutdown pin is available which reduces the Idd1 current to only 15 uA, making them suitable for battery-powered and other power-sensitive applications.
The high common-mode transient immunity (15kV/us) of the ACPL-C87B/C87A/C870 provides the precision and stability needed to accurately monitor DC-link voltage in high noise environments. Combined with superior optical coupling technology, the ACPL-C87B/C87A/C870 implements sigma-delta modulation, chopper stabilized amplifiers, and differential outputs to provide unequaled isolation-mode noise rejection, low offset, high gain accuracy and stability. This performance is delivered in a compact, auto-insertable Stretched SO-8 (SSO-8) package that meets worldwide regulatory safety standards.
