TPD2E007DCKR - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoTPD2E007DCKR
-
ManufacturerTI
-
ChipWorker Part#CW2926600
-
CategoryTVS Diode
-
PackageSC-70-3
-
Description2Channel ESD Protection Array for AC Signal Data Interface 3-SC70 -40℃ to 85℃
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
TPD2E007DCKR Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
TPD2E007DCKR Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | TPD2E007DCKR |
| Manufacturer | TI |
| ChipWorker Part# | CW2926600 |
| Category | TVS Diode |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SC-70-3 |
| Operating Voltage | 13 V |
| Capacitance | 15 pF |
| Breakdown Voltage | 14 V |
| Number of Channels | 2 Channel |
| Number of Positions | 3 Position |
| Power Dissipation | 218 mW |
| Clamping Voltage | 14 V |
| Test Current | 10 mA |
| Peak Pulse Power | 150 W |
| Min Breakdown Voltage | 14 V |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 218 mW |
| expand all | |
| Size-Length | 2.15 mm |
| Size-Width | 1.4 mm |
| Size-Height | 1 mm |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
Product Description
- The TPD2E007DCKR is a 2-channel ESD Protection TVS Diode Array for AC-coupled/negative-rail data interfaces. The back-to-back diode array allows AC-coupled or negative-going data transmission (audio interface, LVDS, RS-485, RS-232 and so forth) without compromising signal integrity. The device exceeds the IEC 61000-4-2 (level 4) ESD protection and is ideal for providing system level ESD protection for the internal ICs when placed near the connector. It is suitable for ultra-space saving application where the package height is a key concern.
- IEC 61000-4-2 level 4 ESD Protection ±8kV IEC 61000-4-2 contact discharge
- ±15kV IEC 61000-4-2 air-gap discharge
- IEC 61000-4-5 Surge protection 4.5A peak pulse current (8/20µs pulse)
- 15pF Maximum IO capacitance
- 50nA Low leakage current
- Space-saving PicoStar™
- -40 to 85°C Operating temperature range
