AD6676 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD6676
Manufacturer	ADI
ChipWorker Part#	CW1205255200
Documentation	Datasheet
	expand all
Product Lifecycle Status	Recommended for New Designs

Similar & Replacement Parts

Product Description

Product Details
### For a limited time, take a live test drive of the AD6676 by using our remote evaluation software.
The AD6676 is a highly integrated IF subsystem that can digitize radio frequency (RF) bands up to 160 MHz in width centered on an intermediate frequency (IF) of 70 MHz to 450 MHz. Unlike traditional Nyquist IF sampling ADCs, the AD6676 relies on a tunable band-pass Σ-Δ ADC with a high oversampling ratio to eliminate the need for band specific IF SAW filters and gain stages, resulting in significant simplification of the wideband radio receiver architecture. On-chip quadrature digital downconversion followed by selectable decimation filters reduces the complex data rate to a manageable rate between 62.5 MSPS to 266.7 MSPS. The 16-bit complex output data is transferred to the host via a single or dual lane JESD204B interface supporting line rates of up to 5.333 Gbps.
Applications
Wideband cellular infrastructure equipment and repeaters
Point-to-point microwave equipment
Instrumentation
Spectrum and communication analyzers
Software defined radio
### Features and Benefits
High instantaneous dynamic range
Noise figure (NF) as low as 13 dB
Noise spectral density (NSD) as low as −159 dBFS/Hz
IIP3 up to 36.9 dBm with spurious tones <−99 dBFS
Tunable band-pass Σ-Δ analog-to-digital converter (ADC)
20 MHz to 160 MHz signal bandwidth
70 MHz to 450 MHz IF center frequency
Configurable input full-scale level of −2 dBm to −14 dBm
Easy to drive resistive IF input
Gain flatness of 1 dB with under 0.5 dB out-of-band peaking
Alias rejection greater than 50 dB
2.0 GSPS to 3.2 GSPS ADC clock rate
On-chip PLL clock multiplier
16-bit I/Q rate up to 266 MSPS
On-chip digital signal processing
NCO and quadrature digital downconverter (QDDC)
Selectable decimation factor of 12, 16, 24, and 32
Automatic gain control (AGC) support
On-chip attenuator with 27 dB span in 1 dB steps
Fast attenuator control via configurable AGC data port
Peak detection flags with programmable thresholds
Single or dual lane, JESD204B capable
Low power consumption: 1.20 W
1.1 V and 2.5 V supply voltage
TDD power saving up to 60%
4.3 mm × 5.0 mm WLCSP
