AD708 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD708
Manufacturer

ADI
ChipWorker Part#

CW181914303
RoHS

Lead free / RoHS Compliant
Description

Ultralow Offset Voltage Dual Op Amp
Documentation

Datasheet

AD708 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD708 Specifications

Attribute	Attribute Value

Part Number	AD708
Manufacturer	ADI
ChipWorker Part#	CW181914303
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	DIP
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant

Product Description

GENERAL DESCRIPTION
The AD708 is a high precision, dual monolithic operational amplifier. Each amplifier individually offers excellent dc precision with maximum offset voltage and offset voltage drift of any dual bipolar op amp.
The matching specifications are among the best available in any dual op amp. In addition, the AD708 provides 5 V/μV minimum open-loop gain and guaranteed maximum input voltage
noise of 350 nV p-p (0.1 Hz to 10 Hz). All dc specifications show excellent stability over temperature, with offset voltage drift typically 0.1 μV/°C and input bias current drift of
25 pA/°C maximum.
FEATURES
Very high dc precision
30 μV maximum offset voltage
0.3 μV/°C maximum offset voltage drift
0.35 μV p-p maximum voltage noise (0.1 Hz to 10 Hz)
5 million V/V minimum open-loop gain
130 dB minimum CMRR
120 dB minimum PSRR
Matching characteristics
30 μV maximum offset voltage match
0.3 μV/°C maximum offset voltage drift match
130 dB minimum CMRR match
Available in 8-lead narrow body, PDIP, and hermetic CERDIP and CERDIP/883B packages
