AD7291BCPZ ,Analog to Digital, ADC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

207 points

Part No

AD7291BCPZ
Manufacturer

ADI
ChipWorker Part#

CW113446
Category

Analog to Digital, ADC IC
Package

LFCSP-20
Description

ANALOG DEVICES AD7291BCPZ Analog to Digital Converter, 12Bit, 22.22KSPS, Single, 1.65V, 3.6V, LFCSP
Documentation

Datasheet
Ships from

Moscow
Наличие

4 pcs In Stock
Estimated Price

$ 11.28

Buy AD7291BCPZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD7291BCPZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD7291BCPZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD7291BCPZ
Manufacturer	ADI
ChipWorker Part#	CW113446
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	LFCSP-20
Supply Voltage (DC)	1.65V (min)
Number of Circuits	1 Circuit
Number of Channels	8 Channel
Number of Positions	20 Position
Number of Bits	12 Bit
Power Dissipation	12.6 W
Sample Rate	22.22 ksps
Resolution (Bits)	12.0 Bit
Input Capacitance	34.0 pF
Number of ADCs	1 ADC
Number of Inputs	8 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	12.6 mW
Number of Input Channels	8 Channel
Supply Voltage	1.65V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	1.65 V
Input Voltage	2.5 V
	expand all
Size-Length	4.1 mm
Size-Width	4.1 mm
Size-Height	0.73 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The AD7291BCPZ is a 12-bit low power successive approximation Analog-to-digital Converter (ADC) with an internal temperature sensor. The part contains a 9-channel multiplexer and a track-and-hold amplifier than can handle frequencies up to 30MHz. The device has an on-chip 2.5V reference that can be disabled to allow the use of an external reference. It provides a 2-wire serial interface compatible with I²C interfaces. The I²C interface supports standard and fast I²C interface modes. The converter normally remains in a partial power-down state while not converting and powers up for conversions. The conversion process can be controlled by a command mode where conversions occur across I²C write operations or an auto-cycle mode selected through software control. It offers a programmable sequencer, which enables the selection of a pre-programmable sequence of channels for conversion.
