AD7731BR ,Analog to Digital, ADC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

133 points

Part No

AD7731BR
Manufacturer

ADI
ChipWorker Part#

CW37723896
Category

Analog to Digital, ADC IC
Package

SOIC-24
Description

5Channel Single ADC Delta-Sigma 6.4KSPS 24Bit Serial 24Pin SOIC W Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

6206 pcs In Stock
Estimated Price

$ 15.74

Buy AD7731BR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD7731BR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD7731BR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD7731BR
Manufacturer	ADI
ChipWorker Part#	CW37723896
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	SOIC-24
Number of Circuits	1 Circuit
Number of Channels	3 Channel
Number of Bits	24 Bit
Power Dissipation	67.5 mW
Sample Rate	6.4 ksps
Resolution (Bits)	24.0 Bit
Input Impedance	9.00 GΩ
Number of ADCs	1 ADC
Number of Inputs	3, 5 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	67.5 mW
Number of Input Channels	3, 5 Channel
	expand all
Size-Length	15.6 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
Mil-Spec	No
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AD7731 is a complete analog front-end for process control applications. The device has a proprietary programmable gain front end that allows it to accept a range of input signal ranges, including low level signals, directly from a transducer. The sigmadelta architecture of the part consists of an analog modulator and a low pass programmable digital filter, allowing adjustment of filter cutoff, output rate and settling time.
The part features three buffered differential programmable gain analog inputs (which can be configured as five pseudo-differential inputs), as well as a differential reference input. The part operates from a single +5 V supply and accepts seven unipolar analog input ranges: 0 to +20 mV, +40 mV, +80 mV, +160 mV, +320 mV, +640 mV and +1.28 V, and seven bipolar ranges: ±20 mV, ±40 mV, ±80 mV, ±160 mV, ±320 mV, ±640 mV and ±1.28 V. The peak-to-peak resolution achievable directly from the part is 16 bits at an 800 Hz output rate. The part can switch between channels with 1 ms settling time and maintain a performance level of 13 bits of peak-to-peak resolution.
The serial interface on the part can be configured for three-wire operation and is compatible with microcontrollers and digital signal processors. The AD7731 contains self-calibration and system calibration options and features an offset drift of less than 5 nV/°C and a gain drift of less than 2 ppm/°C.
The part is available in a 24-lead plastic DIP, a 24-lead SOIC and 24-lead TSSOP package.
**Applications**
Process Control
PLCs/DCS
Industrial Instrumentation
