Part No

AD8421BRMZ
Manufacturer

ADI
ChipWorker Part#

CW616595
Category

Instrumentation Amplifier IC
Package

MSOP-8
Description

ANALOG DEVICES AD8421BRMZ Instrument Amplifier, 1, 25V, 35V/ s, 10MHz, 5V to 36V, MSOP
Documentation

Datasheet

AD8421BRMZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD8421BRMZ Specifications

Attribute	Attribute Value

Part Number	AD8421BRMZ
Manufacturer	ADI
ChipWorker Part#	CW616595
Category	Instrumentation Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Current	2 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	94 dB
Bandwidth	10 MHz
Slew Rate	35.0 V/μs
Gain Bandwidth Product	10 MHz
Input Offset Voltage	25 µV
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	10 MHz
Minimum CMRR Range	80 dB
Supply Voltage	5V ~ 36V
Supply Voltage (Max)	30V ~ 50V
Supply Voltage (Min)	5 V
Input Voltage	5V ~ 36V
	expand all
Size-Length	3.2 mm
Size-Width	3.2 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The AD8421BRMZ is a low power extremely low noise high speed Instrumentation Amplifier ideally suited for a broad spectrum of signal conditioning and data acquisition applications. This product features extremely high CMRR, allowing it to extract low level signals in the presence of high frequency common-mode noise over a wide temperature range. The 10MHz bandwidth, 35V/µs slew rate and 0.6µs settling time to 0.001% (G=10) allow the AD8421 to amplify high speed signals and excel in applications that require high channel count, multiplexed systems. Even at higher gains, the current feedback architecture maintains high performance, for example, at G=100, the bandwidth is 2MHz and the settling time is 0.8µs. The AD8421 has excellent distortion performance, making it suitable for use in demanding applications such as vibration analysis.
Ultralow bias current
Low noise
Excellent AC specifications
High precision DC performance
Inputs protected to 40V from opposite supply
Gain set with a single resistor (G=1 to 10000)

expand all
