AD8620AR - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD8620AR
Manufacturer

ADI
ChipWorker Part#

CW11700619
Category

Amplifier, Buffer IC
Package

SOIC-8
Description

IC OPAMP JFET 25MHz 8SOIC
Documentation

Datasheet

AD8620AR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD8620AR Specifications

Attribute	Attribute Value

Part Number	AD8620AR
Manufacturer	ADI
ChipWorker Part#	CW11700619
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	3 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Common Mode Rejection Ratio	90 dB
Input Capacitance	15.0 pF
Slew Rate	60.0 V/μs
Gain Bandwidth Product	25 MHz
Input Impedance	1.00 TΩ
Input Offset Voltage	85 µV
Input Bias Current	3 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	25 MHz
Minimum CMRR Range	90 dB
Supply Voltage (Max)	27 V
Supply Voltage (Min)	10 V
	expand all
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
Mil-Spec	No
HK STC License	NLR

Product Description

Increase functionality to your signal processing circuit with this general purpose amplifier AD8620AR OP amp from Analog Devices. Its typical dual supply voltage is ±9|±12 V, with a minimum of ±5 V and maximum of ±13 V. This op amp has a temperature range of -40 °C to 125 °C. It has 2 channels per chip. This device uses dual power supplies. This device utilizes bifet technology.
