AD9835BRU - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD9835BRU
Manufacturer

ADI
ChipWorker Part#

CW40576742
Category

Active Chip
Package

TSSOP-16
Description

Direct Digital Synthesizer 50MHz 1DAC 10Bit Serial 16Pin TSSOP Tube
Documentation

Datasheet

AD9835BRU Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD9835BRU Specifications

Attribute	Attribute Value

Part Number	AD9835BRU
Manufacturer	ADI
ChipWorker Part#	CW40576742
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Supply Voltage (DC)	5.00 V
Number of Outputs	1 Output
Output Current	4 mA
Supply Current	40.0 mA
Number of Channels	1 Channel
Number of Bits	10 Bit
Power Dissipation	200 mW
Power Consumption	200 mW
Resolution (Bits)	10.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage	4.75V ~ 5.25V
	expand all
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Product Description

Direct Digital Synthesis IC 10 b 50MHz 32 b Tuning 16-TSSOP
