IRLML5203GTRPBF - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IRLML5203GTRPBF
Manufacturer

Infineon
ChipWorker Part#

CW69792000
Category

MOSFET, MOSFET Transistor
Package

SOT-23-3
Description

SOT-23P-CH 30V 0.76A
Documentation

Datasheet

IRLML5203GTRPBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IRLML5203GTRPBF Specifications

Attribute	Attribute Value

Part Number	IRLML5203GTRPBF
Manufacturer	Infineon
ChipWorker Part#	CW69792000
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	165 mΩ
Polarity	P-Channel
Power Dissipation	1.25 W
Drain to Source Voltage (Vds)	30 V
Breakdown Voltage (Drain to Source)	30 V
Continuous Drain Current (Ids)	0.76A
Rise Time	8.2 ns
Input Capacitance (Ciss)	510pF @25V(Vds)
Input Power (Max)	1.25 W
Fall Time	16 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1.25W (Ta)
	expand all
Size-Length	3.04 mm
Size-Width	1.3 mm
Size-Height	1.02 mm
Material	Silicon
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

SP001567222
