ADCMP551 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADCMP551
Manufacturer

ADI
ChipWorker Part#

CW430795009
Description

Single - Supply, High Speed PECL Comparator in 16 - Lead QSOP Package
Documentation

Datasheet

ADCMP551 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADCMP551 Specifications

Attribute	Attribute Value

Part Number	ADCMP551
Manufacturer	ADI
ChipWorker Part#	CW430795009
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active

Product Description

Product Details
The ADCMP551/ADCMP552/ADCMP553 are single supply, high speed comparators fabricated on Analog Devices’ proprietary XFCB process. The devices feature a 750 ps propagation delay with less than 150 ps overdrive dispersion. Dispersion, a measure of the difference in propagation delay under differing overdrive conditions, is a particularly important characteristic of high speed comparators. A separate programmable hysteresis pin is available on the ADCMP552.
A differential input stage permits consistent propagation delay with a common-mode range from –0.2 V to VCCI – 2.0 V. Outputs are complementary digital signals are fully compatible with PECL 10 K and 10 KH logic families. The outputs provide sufficient drive current to directly drive transmission lines terminated in 50 Ω to VCCO - 2 V. A latch input is included and permits tracking, track-and-hold, or sample-and-hold modes of operation. The latch input pins contain internal pullups that set the latch in tracking mode when left open.
The ADCMP551/ADCMP552/ADCMP553 are specified over the –40°C to +85°C industrial temperature range. The ADCMP551 is available in a 16-lead QSOP package; the ADCMP552 is available in a 20-lead QSOP package; and the ADCMP553 is available in an 8-lead MSOP package.
### Features and Benefits
Single Power Supply
750 ps Propagation Delay Input to Output
100 ps Propagation Delay Dispersion
Differential PECL Compatible Outputs
Differential Latch Control
Internal Latch Pull-up Resistors
750 ps Minimum Pulse Width
Power Supply Rejection Greater than 70 dB
Equivalent Input Rise Time Bandwidth > 750 MHz
Typical Output Rise/Fall of 500 ps
Programmable Hysteresis
