ADG1412YRUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADG1412YRUZ
Manufacturer

ADI
ChipWorker Part#

CW623213
Category

Analog Switch Ic, Analog Switch Multiplexer
Package

TSSOP-16
Description

ANALOG DEVICES ADG1412YRUZ Analogue Switch, Quad Channel, SPST, 4Channels, 1.5Ω, TSSOP, 16Pins
Documentation

Datasheet

ADG1412YRUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADG1412YRUZ Specifications

Attribute	Attribute Value

Part Number	ADG1412YRUZ
Manufacturer	ADI
ChipWorker Part#	CW623213
Category	Analog Switch Ic, Analog Switch Multiplexer
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	4 Output
Supply Current	220 µA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	16 Position
Power Dissipation	4.97 mW
Bandwidth	170 MHz
Number of Inputs	4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	170 MHz
	expand all
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The ADG1412YRUZ is a single-pole single-throw (SPST) monolithic quad iCMOS Analog Switch designed for sample-and-hold systems. iCMOS (industrial CMOS) is a modular manufacturing process combining high voltage CMOS and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33V operation in a footprint that no previous generation of high voltage devices has been able to achieve. Unlike analog ICs using conventional CMOS processes, iCMOS components can tolerate high supply voltages while providing increased performance, dramatically lower power consumption and reduced package size. The on-resistance profile is very flat over the full analog input range, ensuring excellent linearity and low distortion when switching signals. iCMOS construction ensures ultralow power dissipation, making the devices ideally suited for many applications.
No VL supply required
Rail-to-rail operation
3V Logic-compatible inputs
Minimum distortion
<0.03µW Ultralow power dissipation
0.3R On-resistance flatness
0.1R On-resistance match between channels
