ADG211A Specifications

Attribute	Attribute Value

Part Number	ADG211A
Manufacturer	ADI
ChipWorker Part#	CW480095876
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active

Product Description

Product Details
The ADG211A is a monolithic CMOS device comprising four independently selectable switches. They are designed on an enhanced LC2MOS process which gives an increased signal handling capability of ±15 V. These switches also feature high switching speeds and low RON.
The ADG211A switches are turned on with a logic low on the appropriate control input. Each switch conducts equally well in both directions when ON and each has an input signal range that extends to the supplies. All switches exhibit break-before-make switching action for use in multiplexer applications. Inherent in the design is low charge injection for minimum transients when switching the digital inputs.
### Features and Benefits
44 V Supply Maximum Ratings
± 15 V Analog Signal Range
Low On-Resistance (115 O max)
Low Leakage (0.5 nA typ)
Break-Before-Make Switching Action
Single Supply Operation Possible
Extended Plastic Temperature Range
(-40°C to +85°C)
TTL/CMOS Compatible
Superior Second Source for DG211
16-Lead DIP/SOIC and 20-Lead
PLCC Packages
