ADIS16365BMLZ ,Acceleration Sensor, Accelerometer - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

166 points

Part No

ADIS16365BMLZ
Manufacturer

ADI
ChipWorker Part#

CW899904
Category

Acceleration Sensor, Accelerometer
Description

ANALOG DEVICES ADIS16365BMLZ MEMS Module, Inertial, Tri-Axis Gyroscope, Tri-Axis Accelerometer, 4.75V, 5.25V, Module, 24Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 717.98

Buy ADIS16365BMLZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADIS16365BMLZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADIS16365BMLZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADIS16365BMLZ
Manufacturer	ADI
ChipWorker Part#	CW899904
Category	Acceleration Sensor, Accelerometer
Documentation	Datasheet
Number of Pins	24 Pin
Supply Voltage (DC)	4.75V (min)
Supply Current	49 mA
Number of Positions	24 Position
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5 V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	37.26 mm
Size-Width	31.7 mm
Size-Height	23.25 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	Compliant with Exemption
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	7A994

Similar & Replacement Parts

Similar products

Product Description

The ADIS16365BMLZ is an iSensor® Inertial Systems that include a 3-axis gyroscope and triaxis accelerometer. The device combines industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The device provides a simple method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. An improved SPI interface and register structure provide faster data collection and configuration control. The device uses a compatible pin-out and the same package as the ADIS1635x family.
<0.05° Tight orthogonal alignment
330Hz Wide sensor bandwidth
Autonomous operation and data collection no external configuration commands required
180ms Start-up time
4ms Sleep mode recovery
Factory-calibrated sensitivity, bias and axial alignment
-40 to 85°C Calibration temperature range
Embedded temperature sensor
Automatic and manual bias correction controls
Bartlett window FIR filter length, number of taps
Digital I/O - Data-ready, alarm indicator, general-purpose
Alarms for condition monitoring
Sleep mode for power management
Enable external sample clock input up to 1.2kHz
2000g Shock survivability
