TDA7560 - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TDA7560
Manufacturer

ST Microelectronics
ChipWorker Part#

CW56999763
Category

Audio Amplifier IC
Package

25-Flexiwatt
Description

Audio Power Amplifier, AB, 4Channel, 43W, 18V, Flexiwatt25, 25Pins
Documentation

Datasheet

TDA7560 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TDA7560 Specifications

Attribute	Attribute Value

Part Number	TDA7560
Manufacturer	ST Microelectronics
ChipWorker Part#	CW56999763
Category	Audio Amplifier IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	25 Pin
Case/Package	25-Flexiwatt
Supply Voltage (DC)	18.0V (max)
Number of Circuits	1 Circuit
Number of Channels	4 Channel
Power Dissipation	80000 mW
Quiescent Current	200 mA
Output Power	43 W
Output Current (Max)	10000 mA
Operating Temperature (Max)	150 ℃
Power Dissipation (Max)	80000 mW
Supply Voltage	8V ~ 18V
	expand all
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Product Description

Amplifier IC 4-Channel (Quad) Class AB 25-Flexiwatt (Vertical)
