ADL5380 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADL5380
Manufacturer	ADI
ChipWorker Part#	CW389481346
Documentation	Datasheet
	expand all
Product Lifecycle Status	Recommended for New Designs
RoHS	RoHS Compliant

Similar & Replacement Parts

Similar products

Product Description

Product Details
The ADL5380 is a broadband quadrature I-Q demodulator that covers an RF/IF input frequency range from 400 MHz to 6 GHz. With a NF = 10.9 dB, IP1dB = 11.6 dBm, and IIP3 = 29.7 dBm @ 900 MHz, the ADL5380 demodulator offers outstanding dynamic range suitable for the demanding infrastructure direct-conversion requirements. The differential RF inputs provide a well-behaved broadband input impedance of 50 Ω and are best driven from a 1:1 balun for optimum performance.
Excellent demodulation accuracy is achieved with amplitude and phase balances of ~0.07 dB and ~0.2°, respectively. The demodulated in-phase (I) and quadrature (Q) differential outputs are fully buffered and provide a voltage conversion gain of ~7 dB. The buffered baseband outputs are capable of driving a 2 V p-p differential signal into 200 Ω.
The fully balanced design minimizes effects from second-order distortion. The leakage from the LO port to the RF port is <−50 dBm. Differential dc offsets at the I and Q outputs are typically <20 mV. Both of these factors contribute to the excellent IIP2 specification, which is >65 dBm.
The ADL5380 operates off a single 4.75 V to 5.25 V supply. The supply current is adjustable by placing an external resistor from the ADJ pin to either the positive supply, VS, (to increase supply current and improve IIP3) or to ground (which decreases supply current at the expense of IIP3).
The ADL5380 is fabricated using the Analog Devices, Inc., advanced silicon-germanium bipolar process and is available in a 24-lead exposed paddle LFCSP.
**Applications**
* Cellular W-CDMA/GSM/LTE
* Microwave point-to-(multi)point radios
* Broadband wireless and WiMAX
### Features and Benefits
Operating RF and LO frequency: 400 MHz to
6 GHz
Input IP3
30 dBm @ 900 MHz
28 dBm @1900 MHz
Input IP2: >65 dBm @ 900 MHz
Input P1dB (IP1dB): 11.6 dBm @ 900 MHz
Voltage conversion gain: ~7 dB
Demodulation bandwidth: ~390 MHz
Noise figure (NF)
10.9 dB @ 900 MHz
11.7 dB @ 1900 MHz
Quadrature demodulation accuracy @
900 MHz
Phase accuracy: ~0.2°
Amplitude balance: ~0.07 dB
Baseband I/Q drive: 2 V p-p into 200 Ω
Single 5 V supply
