ADM3202ANZ ,Interface IC, Interface Controller - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

194 points

Part No

ADM3202ANZ
Manufacturer

ADI
ChipWorker Part#

CW854648
Category

Interface IC, Interface Controller
Package

DIP-16
Description

Dual Transmitter/Receiver RS-232 16Pin PDIP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 4.5

Buy ADM3202ANZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADM3202ANZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADM3202ANZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADM3202ANZ
Manufacturer	ADI
ChipWorker Part#	CW854648
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	3.00V (min)
Supply Current	12 mA
Number of Positions	16 Position
Data Rate	460 kbps
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	20.07 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The ADM3202ANZ is a 2-channel High Speed RS-232 Line Driver/Receiver that operates from a single 3.3V power supply. Low power consumption makes it ideal for battery-powered portable instruments. It operates at data rates of up to 460kbps. Four external 0.1µF charge pump capacitors are used for the voltage doubler/inverter, permitting operation from a single 3.3V supply.
460kbps Data rate
0.1µF Charge pump capacitors
±8kV Contact discharge
±15kV Air gap discharge
ESD sensitive device, take proper precaution while handling the device.
