SN75176BD ,Interface IC, Interface Controller - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

173 points

Part No

SN75176BD
Manufacturer

TI
ChipWorker Part#

CW1524040
Category

Interface IC, Interface Controller
Package

SOIC-8
Description

Interface IC - transceivers Texas Instruments SN 75176 BD SMD RS422, RS485 1/1 SOIC 8
Documentation

Datasheet
Ships from

Moscow
Наличие

38180 pcs In Stock
Estimated Price

$ 0.19

Buy SN75176BD

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN75176BD Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN75176BD Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN75176BD
Manufacturer	TI
ChipWorker Part#	CW1524040
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	4.75V (min)
Input Voltage (DC)	2.00 V
Output Current	60.0 mA
Supply Current	70 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Drivers Per Package	1
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	4.9 mm
Size-Width	3.91 mm
Size-Height	1.58 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SN75176BD differential bus transceiver is an integrated circuits designed for bidirectional data communication on multipoint bus transmission lines. They are designed for balanced transmission lines and meet ANSI Standards TIA/EIA-422-B and TIA/EIA-485-A and ITU Recommendations V.11 and X.27. This device combines a 3 state differential line driver and a differential input line receiver, both of which operate from a single 5V power supply. The driver and receiver have active high and active low enables, respectively, that can be connected together externally to function as a direction control. The driver differential outputs and the receiver differential inputs are connected internally to form differential input/output (I/O) bus ports that are designed to offer minimum loading to the bus when the driver is disabled or VCC = 0. These ports feature wide positive and negative common-mode voltage ranges, making the device suitable for party line applications.
Bidirectional transceiver
Designed for multipoint transmission on long bus lines in noisy environments
3 state driver and receiver outputs
Individual driver and receiver enables
Wide positive and negative input/output bus voltage ranges
Driver output capability: ±60mA max.
Thermal shutdown protection
Driver positive and negative current limiting
Receiver input impedance: 12kR min.
Receiver input sensitivity: ±200mV
Receiver input hysteresis: 50mV typ.
