ADN2531ACPZ-R2 ,Active Chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

78 points

Part No

ADN2531ACPZ-R2
Manufacturer

ADI
ChipWorker Part#

CW50451428
Category

Active Chip
Package

VFQFN-16
Description

Laser Driver VCSEL/FP/DFB 11.3Gbps 1CH 16Pin LFCSP EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

6730 pcs In Stock
Estimated Price

$ 17.11

Buy ADN2531ACPZ-R2

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADN2531ACPZ-R2 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADN2531ACPZ-R2 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADN2531ACPZ-R2
Manufacturer	ADI
ChipWorker Part#	CW50451428
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	VFQFN-16
Supply Current	36 mA
Number of Channels	1 Channel
Data Rate	11.3 Gbps
Input Bias Current	100 mA
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 3.6V
	expand all
Size-Height	0.73 mm
Operating Temperature	-40℃ ~ 100℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

Product Details
The ADN2531 laser diode driver can work with directly modulated laser diodes, including vertical-cavity surface-emitting laser (VCSEL), Fabry-Perot (FP) lasers, and distributed feedback (DFB) lasers, with a differential loading resistance ranging from 5 Ω to 140 Ω. The active back-termination in the ADN2531 absorbs signal reflections from the laser diode side of the output transmission lines, enabling excellent optical eye quality even when the TOSA end of the output transmission lines is significantly mismatched. The ADN2531 is a SFP+ MSA-compliant device, and small package and enhanced ESD protection provides the optimum solution for compact modules in which laser diodes are packaged in low pin-count optical subassemblies.
The modulation and bias currents are programmable via the MSET and BSET control pins. By driving these pins with control voltages, the user has the flexibility to implement various average optical power and extinction ratio control schemes, including a closed-loop or a look-up table control. The automatic laser shutdown (ALS) feature allows turning the bias on and off while simultaneously modulating currents by driving the ALS pin with a low voltage transistor-to-transistor logic (LVTTL) source.
The product is available in a space-saving, 3 mm × 3 mm LFCSP package and operates from −40°C to +100°C.
**Applications**
Optical transmitters, up to 11.3 Gbps, for SONET/SDH, Ethernet, and Fibre Channel applications
SFF/SFP/SFP+/XFP/X2/XENPAK/XPAK MSA compliant
300-pin optical modules, up to 11.3 Gbps
### Features and Benefits
3.3 V operation
Up to 11.3 Gbps operation
Typical 26 ps rise/fall times
Bias current range: 10 mA to 100 mA
Differential modulation current range: 10 mA to 80 mA
Voltage input control for bias and modulation currents
Data inputs sensitivity: 150 mV p-p differential
Automatic laser shutdown (ALS)
Crosspoint adjustment (CPA)
VCSEL, FP, DFB laser support
SFF/SFP/XFP/SFP+ MSA compliant
Optical evaluation board available
Compact, 3 mm × 3 mm LFCSP
