ADP3624
Manufacturer

ADI
ChipWorker Part#

CW389475475
RoHS

Lead free / RoHS Compliant
Description

High Speed, Dual, 4A MOSFET Driver, non-inverting A/B input pins, 4.5V < Vin < 18V
Documentation

Datasheet

ADP3624 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

ADP3624 Specifications

Attribute	Attribute Value

Part Number	ADP3624
Manufacturer	ADI
ChipWorker Part#	CW389475475
Documentation	Datasheet
Case/Package	8L-MSOP
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant

Product Description

GENERAL DESCRIPTION
The ADP362x/ADP363x is a family of high current and dual high speed drivers, capable of driving two independent N-channel power MOSFETs. The family uses the industry-standard foot print but adds high speed switching performance and improved system reliability.
The family has an internal temperature sensor and provides two levels of overtemperature protection, an overtemperature warning, and an overtemperature shutdown at extreme junction temperatures.
FEATURES
Industry-standard-compatible pinout
High current drive capability
Precise threshold shutdown comparator
UVLO with hysteresis
Overtemperature warning signal
Overtemperature shutdown
3.3 V-compatible inputs
10 ns typical rise time and fall time @ 2.2 nF load
Matched propagation delays between channels
Fast propagation delay
9.5 V to 18 V supply voltage (ADP3633/ADP3634/ADP3635)
4.5 V to 18 V supply voltage (ADP3623/ADP3624/ADP3625)
Parallelable dual outputs
Rated from −40°C to +85°C ambient temperature
Thermally enhanced packages, 8-lead SOIC_N_EP and 8-lead MINI_SO_EP
APPLICATIONS
AC-to-dc switch mode power supplies
DC-to-dc power supplies
Synchronous rectification
Motor drives
