ADUM1250SRZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADUM1250SRZ
Manufacturer

ADI
ChipWorker Part#

CW385617
Category

Interface Isolator, Digital Isolator
Package

SOIC-8
Description

Digital Isolator CMOS 4CH 1Mbps 8Pin SOIC N Tube
Documentation

Datasheet

ADUM1250SRZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADUM1250SRZ Specifications

Attribute	Attribute Value

Part Number	ADUM1250SRZ
Manufacturer	ADI
ChipWorker Part#	CW385617
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V (min)
Supply Current	5 mA
Number of Channels	2 Channel
Number of Positions	8 Position
Isolation Voltage	2500 Vrms
Input Current (Min)	5 mA
Maximum Forward Voltage (Max)	5 V
Fall Time (Max)	120 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR

Product Description

The ADUM1250 series hot swappable dual Digital Isolator with non-latching, bidirectional communication channels that are compatible with I²C interfaces. This eliminates the need for splitting I²C signals into separate transmit and receive signals for use with standalone optocouplers. The ADuM1250 provides two bidirectional channels, supporting a complete isolated I²C interface. It contains hot swap circuitry to prevent glitching data when an unpowered card is inserted onto an active bus. It is based on the iCoupler® chip scale transformer technology from Analog Devices, Inc. iCoupler is a magnetic isolation technology with functional, performance, size and power consumption advantages as compared to optocouplers. With the isolator, iCoupler channels can be integrated with semiconductor circuitry, which enables a complete isolated I²C interface to be implemented in a small form factor.
Open-drain interfaces
30mA Current sink capability
1000kHz Operation
