ADUM6201ARIZ ,Interface Isolator, Digital Isolator - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

153 points

Part No

ADUM6201ARIZ
Manufacturer

ADI
ChipWorker Part#

CW267981
Category

Interface Isolator, Digital Isolator
Package

SOIC-16
Description

ANALOG DEVICES ADUM6201ARIZ Digital Isolator, 2Channel, 55ns, 3V, 5.5V, WSOIC, 16Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

5744 pcs In Stock
Estimated Price

$ 9.42

Buy ADUM6201ARIZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADUM6201ARIZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADUM6201ARIZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADUM6201ARIZ
Manufacturer	ADI
ChipWorker Part#	CW267981
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	2.5 ns
Output Current	100 mA
Number of Channels	2 Channel
Number of Positions	16 Position
Rise Time	2.5 ns
Isolation Voltage	5000 Vrms
Input Current (Min)	20 μA
Maximum Forward Voltage (Max)	7 V
Fall Time (Max)	2.5 ns
Fall Time (Max)	2.5 ns
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	13 mm
Size-Width	7.6 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ADUM6201 series dual-channel Digital Isolator with isoPower® an integrated isolated DC-to-DC converter. Based on the Analog Devices, Inc., iCoupler® technology, the DC-to-DC converter provides up to 400mW of regulated. It eliminates the need for a separate, isolated DC-to-DC converter in low power, isolated designs. The iCoupler chip scale transformer technology is used to isolate the logic signals and for the magnetic components of the DC-to-DC converter. The result is a small form factor, total isolation solution. It provides two independent isolation channels in a variety of channel configurations and data rates. The isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissions standards.
