ADXL354 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADXL354
Manufacturer

ADI
ChipWorker Part#

CW413355366
Description

Low Noise, Low Drift, Low Power 3-Axis Accelerometer with analog output
Documentation

Datasheet

ADXL354 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADXL354 Specifications

Attribute	Attribute Value

Part Number	ADXL354
Manufacturer	ADI
ChipWorker Part#	CW413355366
Documentation	Datasheet
	expand all
Product Lifecycle Status	Recommended for New Designs

Product Description

Product Details
The ADXL354 is part of a new family of low noise density, low 0 g offset drift, low power, 3-axis MEMS accelerometers with selectable measurement ranges. The ADXL354B supports the ±2 g and ±4 g ranges, the ADXL354C supports the ±2 g and ±8 g ranges. The ADXL354 offers industry leading noise, offset drift over temperature, and long term stability, enabling precision applications with minimal calibration and with very low power consumption.
The ADXL354 and ADXL355 (digital output. See ADXL355 Product Page) perform high resolution vibration measurement with very low noise to enable the early detection of structural defects via wireless sensor networks. The low power consumption of the new ADXL354 and ADXL355 accelerometers lengthens battery life and allows extended product usage by reducing the time between battery changes. The low noise performance of the ADXL354 and ADXL355 with low power consumption makes it now possible to cost-effectively enable low level vibration measurement applications such as Structural Health Monitoring (SHM). Additionally, the tilt stability of ADXL354 and ADXL355 accelerometers delivers excellent repeatability over temperature and time, which is ideal for orientation and navigation systems in unmanned aerial vehicles using Inertial Measurement Units (IMUs) and inclinometers. By providing repeatable tilt measurement under all conditions, the new accelerometers enable minimal tilt error without extensive calibration in harsh environments.
The ADXL354 and ADXL355 accelerometers offer guaranteed temperature stability with null offset coefficients of 0.15mg/C (max). The stability minimizes resource and expense associated with calibration and testing effort, helping to achieve higher throughput for device OEMs. In addition, the hermetic package helps ensure that the end product conforms to its repeatability and stability specifications long after they leave the factory.
With output of ±2g to ±8g full scale range (FSR), selectable digital filtering from 1 Hz to 1 kHz, and low noise density of 25µ/Hz and150µA current consumption, the ADXL354 MEMS accelerometer offers performance level comparable to much more expensive devices with less power consumption and BOM cost.
Applications
Inertial measurement units (IMUs)/altitude and heading reference systems (AHRS)
Platform stabilization systems
Structural health monitoring
Seismic imaging
Tilt sensing
Robotics
Condition Monitoring
### Features and Benefits
Hermetic package offers excellent long-term stability
0 _g_ offset vs. temperature (all axes): 0.15 mg/°C maximum
Ultralow noise density (all axes): 20µg/√Hz
Low power, VSUPPLY (LDO enabled)
150 µA in measurement mode (digital)
21 µA in standby mode
Adjustable analog output bandwidth
Electromechanical self-test
Integrated temperature sensor
Voltage range options
VSUPPLY with internal regulators: 2.25 V to 3.6 V
V1P8ANA, V1P8DIG with internal low dropout regulator (LDO) bypassed: 1.8 V typical ± 10%
Operating temperature range: -40°C to 125°C
14-terminal, 6 mm × 6 mm × 2.1 mm, LCC package, 0.26 grams
