BAT86 ,Schottky Diode - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

53 points

Part No

BAT86
Manufacturer

NXP
ChipWorker Part#

CW171436800
Category

Schottky Diode
Package

DO-34
Description

Diode Schottky 50V 0.2A 2Pin DO-34
Documentation

Datasheet
Ships from

Moscow
Наличие

9502 pcs In Stock
Estimated Price

$ 0.07

Buy BAT86

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

BAT86 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

BAT86 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	BAT86
Manufacturer	NXP
ChipWorker Part#	CW171436800
Category	Schottky Diode
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-34
Number of Positions	2 Position
Forward Voltage	380 mV
Forward Current	200 mA
Max Forward Surge Current (Ifsm)	5 A
Maximum Forward Voltage (Max)	450 mV
Forward Current (Max)	200 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-65 ℃
	expand all
Size-Length	3.04 mm
Size-Width	1.6 mm
Size-Height	1.6 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The BAT86 is a Planar Schottky Barrier Diode with an integrated guard ring for stress protection. It is encapsulated in a hermetically-sealed sub-miniature package. The diode is suitable for mounting on a 2E (5.08mm) pitch.
