BSC022N04LS6ATMA1 - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

BSC022N04LS6ATMA1
Manufacturer

Infineon
ChipWorker Part#

CW279313129
Description

Trans MOSFET N-CH 40V 27A 8-Pin TDSON EP T/R
Documentation

Datasheet

BSC022N04LS6ATMA1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

BSC022N04LS6ATMA1 Specifications

Attribute	Attribute Value

Part Number	BSC022N04LS6ATMA1
Manufacturer	Infineon
ChipWorker Part#	CW279313129
Documentation	Datasheet
Number of Pins	8 Pin
Rise Time	2.1 ns
Input Capacitance (Ciss)	1900pF @20V(Vds)
Fall Time	4 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3000 mW
	expand all
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	ROHS3 Compliant
Lead-Free Status	Contains Lead

Product Description

N-Channel 40V 27A (Ta), 100A (Tc) 3W (Ta), 79W (Tc) Surface Mount PG-TDSON-8-1
