CD4017BM - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

CD4017BM
Manufacturer

TI
ChipWorker Part#

CW4087061
Category

Counter, Counter IC
Package

SOIC-16
Description

TEXAS INSTRUMENTS CD4017BM Counter / Divider, 11MHz, 3V to 18V, DIP-16
Documentation

Datasheet

CD4017BM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

CD4017BM Specifications

Attribute	Attribute Value

Part Number	CD4017BM
Manufacturer	TI
ChipWorker Part#	CW4087061
Category	Counter, Counter IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Frequency	11 MHz
Supply Voltage (DC)	3.00V (min)
Number of Outputs	10 Output
Number of Positions	16 Position
Clock Speed	11 MHz
Number of Bits	10 Bit
Voltage Nodes	5.00 V, 10.0 V, 15.0 V
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	3V ~ 18V
Supply Voltage (Max)	18 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	9.9 mm
Size-Width	3.91 mm
Size-Height	1.58 mm
Weight	0.0022670548152 kg
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The CD4017BM is a CMOS Decade Counter with 10 decoded outputs. Inputs include a clock, reset and clock inhibit signal. Schmitt trigger action in the clock input circuit provides pulse shaping that allows unlimited clock input pulse rise and fall times. It is advanced one count at the positive clock signal transition if the clock inhibit signal is low. Counter advancement via the clock line is inhibited when the clock inhibit signal is high. A high reset signal clears the counter to its zero count. Use of the Johnson counter configuration permits high-speed operation, 2-input decode-gating and spike-free decoded outputs. Anti-lock gating is provided, thus assuring proper counting sequence. The decoded output is normally low and go high only at their respective decoded time slot. Each decoded output remains high for one full clock cycle. A carry-out signal completes on cycle every 10 clock input cycles and is used to ripple-clock the succeeding device in a multi-device counting chain.
