Part No

CSD16570Q5BT
Manufacturer

TI
ChipWorker Part#

CW4972140
Category

MOSFET, MOSFET Transistor
Package

VSON-Clip-8
Description

VSON-CLIP N-CH 25V 100A
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.75

Buy CSD16570Q5BT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CSD16570Q5BT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CSD16570Q5BT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CSD16570Q5BT
Manufacturer	TI
ChipWorker Part#	CW4972140
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	VSON-Clip-8
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.00049 Ω
Polarity	N-Channel
Power Dissipation	195 W
Threshold Voltage	1.5 V
Drain to Source Voltage (Vds)	25 V
Continuous Drain Current (Ids)	100A
Rise Time	43 ns
Input Capacitance (Ciss)	10700pF @12V(Vds)
Fall Time	72 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3.2W (Ta), 195W (Tc)
	expand all
Size-Length	5 mm
Size-Width	6 mm
Size-Height	1 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The CSD16570Q5BT is a 25V N-channel NexFET™ Power MOSFET is designed to minimize resistance for OR-ing and hot swap applications.
Extremely low resistance
Low Qg and Qgd
Low thermal resistance
Avalanche rated
Halogen-free
