D09P24A4GV00LF ,D-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature - FCI Electronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

134 points

Part No

D09P24A4GV00LF
Manufacturer

FCI Electronics
ChipWorker Part#

CW15322759
Category

D-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature
Package

Metal
Description

Conn D-Subminiature PIN 9POS 2.74mm Solder ST Thru-Hole 9 Terminal 1Port
Documentation

Datasheet
Ships from

Moscow
Наличие

9717 pcs In Stock
Estimated Price

$ 0.88

Buy D09P24A4GV00LF

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

D09P24A4GV00LF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

D09P24A4GV00LF Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	D09P24A4GV00LF
Manufacturer	FCI Electronics
ChipWorker Part#	CW15322759
Category	D-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	Metal
Pin Pitch	2.74 mm
Number of Contacts	9 Contact
Gender	Male
Contact Plating	Gold
Current Rating	5 A
Number of Rows	2 Row
Flammability Rating	UL 94 V-0
Number of Positions	9 Position
Contact Resistance	10.0 mΩ
Number of Mating Cycles	200 Cycle
Voltage Rating	300 V
Operating Voltage (Max)	300 VAC
	expand all
Size-Length	30.81 mm
Size-Width	11.9 mm
Size-Height	11.9 mm
Housing Color	Black
Color	Black
Contact Material	Phosphor Bronze
Material	Steel
Operating Temperature	-55℃ ~ 125℃
Housing Material	Plastic
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The D09P24A4GV00LF is a 9-way straight solder standard D-sub Connector with 4 to 40 UNC thread, harpoon-solder. This Delta D series plug is one of the most popular input to output interconnects.
