NC3FXX ,Audio Connector - Neutrik
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
130 points
-
Part NoNC3FXX
-
ManufacturerNeutrik
-
ChipWorker Part#CW5244129
-
CategoryAudio Connector
-
PackageMetal
-
DescriptionConn XLR Connector F 3POS Solder ST Cable Mount 3 Terminal 1Port
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие13945 pcs In Stock
-
Estimated Price$ 6.07
Payment Methods and Delivery
{{ estimate }}
Buy NC3FXX
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
NC3FXX Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
NC3FXX Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | NC3FXX | |
| Manufacturer | Neutrik | |
| ChipWorker Part# | CW5244129 | |
| Category | Audio Connector | |
| Documentation | Datasheet | |
| Mounting Style | Solder | |
| Number of Pins | 3 Pin | |
| Case/Package | Metal | |
| Number of Contacts | 3 Contact | |
| Gender | Female | |
| Contact Plating | Silver | |
| Current Rating | 16 A | |
| Insulation Resistance | 2000 MΩ | |
| Orientation | Straight | |
| Flammability Rating | UL 94 HB | |
| Number of Positions | 3 Position | |
| Contact Resistance | 3.00 mΩ | |
| Number of Mating Cycles | 1000 Cycle | |
| Current Rating (Max) | 16A/触头 | |
| Operating Temperature (Max) | 80 ℃ | |
| Operating Temperature (Min) | -30 ℃ | |
| Voltage Rating (Max) | 50 V | |
| Voltage Rating | 50 V | |
| Maximum Contact Resistance (Max) | 3 mΩ | |
| expand all | ||
| Size-Length | 73.5 mm | |
| Size-Diameter | 20.4 mm | |
| Color | Nickel | |
| Contact Material | Bronze | |
| Dielectric Material | Nylon | |
| Operating Temperature | -30℃ ~ 80℃ | |
| Housing Material | Zinc Die-Cast | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| HTS Code | 8536694020 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.
- Unique cage design of female contact for low contact resistance and high integrity
- Female contact incorporates a solder barrier to prevent solder running into the contact mating area
- Female connector with improved solid metal latch which is larger and easier to handle
- Additional ground spring contacts for better shell ground continuity
- Improved chuck type strain relief provides higher pull-out force & makes assembly easier and faster
- Boot with polyurethane gland gives high protection to cable bending stresses
- Colored rings and boots available for coding or identification
- Sleek and ergonomic design - valuable and handy
- Rugged zinc diecast shell, longlasting and dependable
- Internal thread on shell is well protected against any damage
