DAC08 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

DAC08
Manufacturer

ADI
ChipWorker Part#

CW353129248
Description

Analog Devices: Data Converters: DAC 8Bit, 10ns to 100ns Converters Selection Table
Documentation

Datasheet

DAC08 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DAC08 Specifications

Attribute	Attribute Value

Part Number	DAC08
Manufacturer	ADI
ChipWorker Part#	CW353129248
Documentation	Datasheet
	expand all
Product Lifecycle Status	Unknown

Product Description

GENERAL DESCRIPTION
The DAC08 series of 8-bit monolithic digital-to-analog convert ers provide very high speed performance coupled with low cost and outstanding applications flexibility.
FEATURES
Fast settling output current: 85 ns
Full-scale current prematched to ±1 LSB
Direct interface to TTL, CMOS, ECL, HTL, PMOS
Nonlinearity to 0.1% maximum over temperature range
High output impedance and compliance: −10 V to +18 V
Complementary current outputs
Wide range multiplying capability: 1 MHz bandwidth
Low FS current drift: ±10 ppm/°C
Wide power supply range: ±4.5 V to ±18 V
Low power consumption: 33 mW @ ±5 V
Low cost
