DAC8581IPW - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

DAC8581IPW
Manufacturer

TI
ChipWorker Part#

CW39249406
Category

Digital to Analog, DAC IC
Package

TSSOP-16
Description

TEXAS INSTRUMENTS DAC8581IPW Digital to Analog Converter, 16Bit, 3MSPS, Serial, ± 4V to ± 6V, TSSOP, 16Pins
Documentation

Datasheet

DAC8581IPW Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

DAC8581IPW Specifications

Attribute	Attribute Value

Part Number	DAC8581IPW
Manufacturer	TI
ChipWorker Part#	CW39249406
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	1 Output
Supply Current	-23.0 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Number of Bits	16 Bit
Power Dissipation	175 mW
Sample Rate	3 Msps
Power Consumption	175 mW
Thermal Shutdown	No
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
	expand all
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The DAC8581IPW is a 16-bit high-speed low-noise Digital-to-analog Converter (DAC) operating from dual ±5V power supplies. The DAC8581 is monotonic and has exceptionally low noise and exceptionally low glitch. The DAC8581 high-performance, bipolar output buffer is capable of settling within 0.65µs for a 10V step. Small-signal settling time is well under 0.3µs, supporting data update rates up to 3MSPS. A power-on-reset circuit sets the output at midscale voltage on power up. The DAC8581 is simple to use with a single external reference and a standard 3-wire SPI interface that allows clock rates up to 50MHz.
Very low glitch - 0.5nV-s
Fast settling - 0.65µs
Fast slew rate - 35V/µs
Single external reference
Power-on reset to mid-scale
Twos complement data format
Hardware reset to mid-scale
Green product and no Sb/Br

expand all
