DRV592VFP ,Power Management IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

149 points

Part No

DRV592VFP
Manufacturer

TI
ChipWorker Part#

CW2925969
Category

Power Management IC
Package

HLQFP-32
Description

Driver 1Out Hi/Lo Side H Brdg Inv 32Pin HLQFP EP
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.72

Buy DRV592VFP

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

DRV592VFP Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

DRV592VFP Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	DRV592VFP
Manufacturer	TI
ChipWorker Part#	CW2925969
Category	Power Management IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	HLQFP-32
Frequency	1.00 MHz
Supply Voltage (DC)	2.80V (min)
Output Current	3 A
Supply Current	500 µA
Number of Channels	1 Channel
Number of Positions	32 Position
Power Dissipation	4.1 W
Quiescent Current	7.00 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	40 ℃
Supply Voltage	2.8V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.8 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

The DRV592VFP is a high-efficiency high-current H-Bridge Driver ideal for driving a wide variety of thermoelectric cooler elements in systems powered from 2.8 to 5.5V and requires external PWM. Low output stage on-resistance significantly decreases power dissipation in the amplifier. The DRV592VFP may be driven from any external PWM generator such as a DSP, a microcontroller or a FPGA. The frequency may vary from DC (i.e., on or off) to 1MHz. The inputs are compatible with TTL logic levels. The DRV592VFP is internally protected against thermal and current overloads. Logic-level fault indicators signal when the junction temperature has reached approximately 130°C to allow for system-level shutdown before the amplifier"s internal thermal shutdown circuitry activates. The fault indicators also signal when an over-current event has occurred. If the over-current circuitry is tripped, the DRV592 automatically resets.
Requires external PWM from DC to 1MHz with TTL-compatible voltages for high and low
High efficiency generates less heat
Over-current and thermal protection
Fault indicators for over-current, thermal and under-voltage conditions
9 x 9mm PowerPAD™ quad flatpack
Green product and no Sb/Br
This IC can be damaged by ESD. We recommend that all ICs be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
