EG1224 ,Slide Switch, Switch Slide - E-Switch

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

95 points

Part No

EG1224
Manufacturer

E-Switch
ChipWorker Part#

CW3713917
Category

Slide Switch, Switch Slide
Package

Through Hole
Description

E-SWITCH EG1224 Slide Switch, SPDT, Through Hole, 500mA
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.82

Buy EG1224

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

EG1224 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

EG1224 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	EG1224
Manufacturer	E-Switch
ChipWorker Part#	CW3713917
Category	Slide Switch, Switch Slide
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	Through Hole
Contact Plating	Silver
Voltage Rating (DC)	15 V
Actuator Type	Standard
Current Rating	500mA (DC)
Insulation Resistance	100 Ω
Orientation	Right Angle
Contacts Type	SPDT
Contact Resistance	20 mΩ
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-20 ℃
Voltage Rating	30 V
	expand all
Size-Length	13.8 mm
Size-Width	15.5 mm
Size-Height	8.5 mm
Contact Material	Copper Alloy
Operating Temperature	-20℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
HTS Code	8536509065
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Switch Slide SPDT Extended Side Slide PC Pins Bracket Mount/Through Hole
