EVAL-ADUM3070EBZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	EVAL-ADUM3070EBZ
Manufacturer	ADI
ChipWorker Part#	CW10927061
Category	Microprocessor Primary Platform
Documentation	Datasheet
Switching Frequency	500 kHz
Operating Temperature (Max)	105 ℃
Input Voltage	5 V
	expand all
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The EVAL-ADUM3070EBZ is an iCoupler ADuM3070 isolated switch regulator with integrated feedback evaluation board. The EVAL-ADuM3070EBZ demonstrates two separate applications for the ADuM3070 isolated switch regulator with integrated feedback. It has two independent power supply circuits, a double supply and a single supply. The switching frequency can be set from 200KHz to 1000KHz. The board supports a variety of I/O configurations and multiple transformer options. It is equipped with two ADuM3070 isolators.
2 independent ADuM3070 circuits including 2.5kV rms isolated dc to dc converters
Single supply 5V in to 5V out (regulated)
Single supply reconfigurable to 5V in to 3.3V out or 3.3V in to 3.3V out
Double supply 5V in to 15V out (regulated) and 7.5V out (unregulated)
Double supply reconfigurable to 5V in to 12V out (regulated) and 6V out (unregulated)
Footprints for coilcraft and halo transformer options
Multiple switching frequency options
