Part No

EZ80F91AZ050SG
Manufacturer

Zilog
ChipWorker Part#

CW124912489
Category

Microcontroller, MCU IC
Package

LQFP-144
Description

MCU 8Bit eZ80A eZ8 CISC 256KB Flash 3.3V 144Pin LQFP
Documentation

Datasheet

EZ80F91AZ050SG Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

EZ80F91AZ050SG Specifications

Attribute	Attribute Value

Part Number	EZ80F91AZ050SG
Manufacturer	Zilog
ChipWorker Part#	CW124912489
Category	Microcontroller, MCU IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	144 Pin
Case/Package	LQFP-144
Frequency	50 MHz
Supply Voltage (DC)	3.30 V, 3.60 V (max)
Clock Speed	50.0 MHz
RAM Memory Size	16K x 8
Number of Bits	8 Bit
FLASH Memory Size	262144 B
Number of I/O Pins	32 IO
Access Time	50.0 µs
Core Architecture	Z8
Memory Size	256000 B
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	20.1 mm
Size-Width	20.1 mm
Size-Height	1.45 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
