FDS3590 - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

FDS3590
Manufacturer

Fairchild
ChipWorker Part#

CW55876040
Category

MOSFET, MOSFET Transistor
Package

SOIC-8
Description

Trans MOSFET N-CH 80V 6.5A 8Pin SOIC N T/R
Documentation

Datasheet

FDS3590 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FDS3590 Specifications

Attribute	Attribute Value

Part Number	FDS3590
Manufacturer	Fairchild
ChipWorker Part#	CW55876040
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Voltage Rating (DC)	80.0 V
Current Rating	6.50 A
Number of Channels	1 Channel
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.032 Ω
Polarity	N-Channel
Power Dissipation	2.5 W
Threshold Voltage	4 V
Input Capacitance	1.18 nF
Gate Charge	25.0 nC
Drain to Source Voltage (Vds)	80 V
Breakdown Voltage (Drain to Source)	80.0 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	6.50 A
Rise Time	8 ns
Input Capacitance (Ciss)	1180pF @40V(Vds)
Input Power (Max)	1 W
Fall Time	12 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2.5W (Ta)
	expand all
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The FDS3590 is a N-channel MOSFET produced using Fairchild Semiconductor"s PowerTrench® process. It is designed specifically to improve the overall efficiency of DC-to-DC converters using either synchronous or conventional switching PWM controllers. It features faster switching and lower gate charge than other MOSFETs with comparable RDS (ON) specifications. The result is a MOSFET that is easy and safer to drive (even at very high frequencies) and DC-to-DC power supply designs with higher overall efficiency.
Low gate charge
Fast switching speed
High performance Trench technology for extremely low RDS (ON)
High power and current handling capability

expand all
