FT232RQ - FTDI Chip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

FT232RQ
Manufacturer

FTDI Chip
ChipWorker Part#

CW8794296
Category

Interface IC, Interface Controller
Package

QFN
Description

FTDI FT232RQ Interface Bridges, USB to UART, 1.8V, 5.25V, QFN, 32Pins, -40℃
Documentation

Datasheet

FT232RQ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FT232RQ Specifications

Attribute	Attribute Value

Part Number	FT232RQ
Manufacturer	FTDI Chip
ChipWorker Part#	CW8794296
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	QFN
Supply Voltage (DC)	3.30V (min)
Supply Current	15.0 mA
Number of Positions	32 Position
Data Rate	3.00 Mbps
Bandwidth	48.0 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	1.8 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

* Single chip USB to asynchronous serial data transfer interface
Entire USB protocol handled on the chip. No USB specific firmware programming required
Fully integrated 1024 bit EEPROM storing device descriptors and CBUS I/O configuration
Fully integrated USB termination resistors
Fully integrated clock generation with no external crystal required
Data transfer rates from 300 baud to 3 Mbaud (RS422, RS485, RS232 ) at TTL levels
128 byte receive buffer and 256 byte transmit buffer
FTDI royalty-free Virtual Com Port & Direct drivers eliminate requirement for USB driver development
Unique USB FTDI Chip-ID feature
Configurable CBUS I/O pins
Transmit and receive LED drive signals
UART interface support for 7 or 8 data bits, 1 or 2 stop bits and odd/even/mark/space/no parity
FIFO receive and transmit buffers for high data throughput
Synchronous and asynchronous bit bang interface options with RD# and WR# strobes
Device supplied pre-programmed with unique USB serial number
Supports bus powered, self powered and high power bus powered USB configurations
Integrated +3.3V level converter for USB I/O
Integrated level converter on UART and CBUS for interfacing to between +1.8V and +5V logic
True 5V/3.3V/2.8V/1.8V CMOS drive output and TTL input
Configurable I/O pin output drive strength
