GLCB01C - Honeywell

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

GLCB01C
Manufacturer

Honeywell
ChipWorker Part#

CW10582476
Category

Switch
Package

zinc diecast
Description

Switch Limit N.O./N.C. SPDT Top Roller Plunger Conduit 6A 600VAC 250VDC 16N Linear Screw Mount
Documentation

Datasheet

GLCB01C Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

GLCB01C Specifications

Attribute	Attribute Value

Part Number	GLCB01C
Manufacturer	Honeywell
ChipWorker Part#	CW10582476
Category	Switch
Documentation	Datasheet
Mounting Style	Screw
Case/Package	zinc diecast
Voltage Rating (DC)	125 V
Actuator Type	Top Roller Plunger
Voltage Rating (AC)	120 V
Current Rating	6A (AC), 550mA (DC)
Contacts Type	SPDT
Current Rating (Max)	6A @120VAC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating (AC Max)	240 V
	expand all
Size-Length	68.5 mm
Size-Width	30.5 mm
Size-Height	89.5 mm
Operating Temperature	-40℃ ~ 85℃
Housing Material	Zinc Die-Cast
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HTS Code	8536509040
ECCN Code	EAR99

Product Description

The GLCB01C is a 1NO/1NC SPDT snap-action Global Limit Switch with top roller plunger actuator. This GLS series MICRO SWITCH™ durable and reliable limit switch is suitable for transportation equipment and other applications requiring an environmentally sealed (IP and NEMA) switch. The compact housing is often ideal for equipment where space is at a premium. The direct-opening, normally closed contacts are designed for safety-related applications. It is suitable for machine tools, material handling equipment, textile machinery, construction machinery and equipment.
Metal miniature body for indoor and outdoor applications
Heads can be positioned at 90° increments for design flexibility
Large existing install base and channel allows for quick delivery worldwide
Silver contacts for power switching
Normally closed contacts are positive opening
Easy to install
Sealed to IP66 and NEMA/UL 1, 4, 12 and 13
Meets EN50047 mounting standards and EN/IEC electrical standards for world-wide use
PG 13.5 Conduit
Do not use this product as safety or emergency stop devices or in any other application where failure of the product could result in personal injury.
