GVAN11 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

GVAN11
Manufacturer

Schneider Electric
ChipWorker Part#

CW3222982
Category

Industrial Relay
Description

SCHNEIDER ELECTRIC / TELEMECANIQUE GVAN11 Switch Contact Block, TeSys GV2 and GV3 Manual Starters and Protectors, 6A, 575V, Screw, 2Pole
Documentation

Datasheet

GVAN11 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

GVAN11 Specifications

Attribute	Attribute Value

Part Number	GVAN11
Manufacturer	Schneider Electric
ChipWorker Part#	CW3222982
Category	Industrial Relay
Documentation	Datasheet
Number of Contacts	2 Contact
Current Rating	10 A
Contact Current Rating	6 A
	expand all
Size-Length	66 mm
Size-Width	9.3 mm
Size-Height	89 mm
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Product Description

The GV family of products are 3-pole, horsepower rated, UL 508 listed, manual starters. They include a manual disconnect, class 10 ambient-compensated thermal overload relay, and an instantaneous magnetic trip mechanism in one compact unit.
Any GV manual starter can be used alone for local manual control of a motor with individual full-load currents up to 220 amps. The GV family of products may also be used in group motor installations in accordance with National Electric Code article 430-53. Group motor installations give you greater panel density for smaller size and require fewer parts and less wiring necessary for installation when compared to conventional panel designs.
